J4 6/24 RTS - 1210375 - 1 - Somfy

Ref : 1210375 - J406 6/24 RTS

J4 6/24 RTS

J4 6/24 RTS

Application
Exterior venetian blinds
Technology
RTS technology

Details and specifications

Programming Instructions for all our products can be found in the Somfy Pocket Book.  You will need to log in to the Somfy Professionals website for access







Other documents & links

Others

Technical information

Technology
Radio Frequency 433,42   MHz
Range in open field 200m
Capacity of memory 12 different transmitters
Coding Rolling code 16 million of possibilities
Range in house 20m through 2 reinforced concrete walls

Electrical
Consumption during operation 95   W
Minimum voltage 253   V
Maximum Voltage 207   V
Rated current 0.5   A
Nominal Voltage / Frequency 230V 50Hz

Mechanical
Capacity of the limit switch unit 200   turns
Type of limit switch unit Electronic
Nominal Speed 24   rpm
Nominal Torque 6   Nm

Standard
Approval RCM
Protection Index IP 54
Insulation class Class I

Cable
Plug in cable STAS3
Cable type PVC
Wire section 0.75   mm²
Color Black
Wire Length 0.5   m
Number of wires of the cable 3

Dimension
Riveting position distance (L2) 47   mm
Weight 1.5   Kg
Overall length (L3) 254   mm
Length (L1) 222   mm

Other
Thermal time 6   mn
Noise level (according to Somfy measures) ≤70   dBA
Working temperature -10 to +40   °C
