GEMINI 25/17 CSI 2.5M White Cable - 1043001 - 1 - Somfy

Ref : 1043001 - LT GEMINI 25/17 CSI VVF 2,5M - UNIT

GEMINI 25/17 CSI 2.5M White Cable

GEMINI 25/17 CSI 2.5M White Cable

Application
Roller shutters,Awnings
Technology
Wired Technology (WT)

Details and specifications

Programming Instructions for all our products can be found in the Somfy Pocket Book.  You will need to log in to the Somfy Professionals website for access

Other documents & links

Others

Technical information

Electrical
Consumption during operation 170   W
Minimum voltage 207   V
Maximum Voltage 244   V
Rated current 0.75   A
Nominal Voltage / Frequency 230V - 50 Hz

Mechanical
Capacity of the limit switch unit 34   turns
Type of limit switch unit Quick limit switch
Nominal Speed 17   rpm
Nominal Torque 20   Nm
Repeatabilty ± 5   °

Standard
Approval RCM
Protection Index IP 44
Insulation class Class I

Cable
Plug in cable Black CSI Plug
Cable type PVC
Wire section 0,75   mm²
Color White
Wire Length 2,5   m
Number of wires of the cable 4

Dimension
Length (L1) 607   mm
Basic crown for tube diameter 50 x 1,5   mm
Weight 2,81   Kg
Overall length (L3) 594   mm
Riveting position distance (L2) 579   mm

Other
Thermal time 4   mn
Noise level (according to Somfy measures) 56   dBA
Working temperature -10 to +40   °C
