Electrical
Consumption during operation	140   W
Minimum voltage	207   V
Maximum Voltage	244   V
Rated current	0.65   A
Nominal Voltage / Frequency	230VAC - 50Hz

Mechanical
Capacity of the limit switch unit	46   turns
Type of limit switch unit	Quick limit switch
Type of head	Star
Nominal Speed	17   rpm
Nominal Torque	15   Nm
Repeatabilty	± 5   °

Standard
Approval	RCM
Protection Index	IP 44
Insulation class	Class I

Cable
Plug in cable	Black LT Plug
Cable type	PVC
Wire section	0,75   mm²
Color	White
Wire Length	2,5   m
Number of wires of the cable	4

Dimension
Length (L1)	533   mm
Basic crown for tube diameter	50 x 1,5   mm
Weight	1,95   Kg
Overall length (L3)	525   mm
Riveting position distance (L2)	510   mm

Other
Thermal time	4   mn
Noise level (according to Somfy measures)	50   dBA
Working temperature	-10 to +40   °C
