Ref : 1001550 - SONESSE 40 6/20 VVF2.5M UNIT

SONESSE 40 6/20 2.5M White Cable

Application
Interior blinds,Projection screen
Technology	Warranty
Wired Technology (WT)	5 Years

Details and specifications

Description

To ensure peak accoustic and mechanical performance use Sonesse 40 accessories only.

Programming Instructions for all our products can be found in the Somfy Pocket Book. You will need to log in to the Somfy Professionals website for access

Technical information

End product
End product type	Roller blinds, Roman blinds, Pleated and cellular blinds, Venetian blinds, Projection screens, Zebra blinds

Electrical
Maximum Voltage	253 V
Minimum voltage	207 V
Consumption during operation	120 W
Consumption in standby mode	0 W
Nominal Voltage / Frequency	AC - RGE 1 - 230V/50HZ
Rated current	0.55 A

Mechanical
Nominal Torque	6 Nm
Nominal Speed	20 rpm
Type of head	ROUND
Type of limit switch unit	Progressive
Capacity of the limit switch unit	40 turns
Repeatabilty	+/- 15 °
Traction force	7 Kg

Standard
Insulation class	Class II
Protection Index	IP 44
Approval	CE

Cable
Wire Length	2.5 m
Number of wires of the cable	3
Wire section	0.75 mm²
Plug in cable	STRIPPED
Cable type	VVF
Color	WHITE

Dimension
Diameter	40 mm
Weight	1.25 Kg
Basic crown for tube diameter	37 mm
Length (L1)	510 mm
Overall length (L3)	510 mm
Riveting position distance (L2)	473 mm

Other
Thermal time	4 mn
Noise level (according to Somfy measures)	45 dBA
Limits of use	For indoor use only Motor should be installed horizontally Do not use for panthograph Restriction: from 0°C to 10°C 1500 cycles. from 35°C to 60°C 3500 cycles.
Thermal tripping	140 °C
